Successfully automated the Samlak heat treatment loading process!๐ We even built a perfect jig design. (ft. Hyundai Robotics Industrial Robot)
Process Overview
This project involved the introduction of automated loading/unloading to ensure uniform heat treatment of the carrier mid-planet, a key component of automotive transmissions. The client implemented automation to address several issues arising from the previously manual process, particularly the increased defect rate and inefficiencies caused by workers. Hyundai Robotics' HH050 six-axis industrial robot was utilized for this purpose, automating various tasks such as product stacking, pin insertion, and tray placement, ensuring high productivity and stability.
Warranty Period
- 1 Year
Performance Year
- 2024
Project Duration
- 3 Months
๊ตฌ์ฑ์์
| ๋ก๋ด | Hyundai Robotics' HH050 six-axis industrial robot ; |
|---|
์์ ์์
| STEP 1. | Product loading part: Manually place the mid-planet on the loading jig, and place 20 products per jig on the 8-segment index table to secure up to 160 product cartridges. |
|---|---|
| STEP 2. | Pin insertion part: The pins for loading are supplied and aligned through the parts feeder and placed on the mid-planet using a single-axis robot + air chuck combination. |
| STEP 3. | Loading part: Loading the mid-planet with the pin inserted, and use the servo-type to precisely control the position of the mid-planet according to its thickness. 2 sets are applied to prevent bottlenecks from occurring even when the laminated product is being discharged. |
| STEP 4. | Tray placement part: Using a 6-axis industrial robot, the loaded products are placed on a tray dedicated to heat treatment, 9 sets of fully loaded products are placed every 60' radius, and when the 360' work is completed, the worker uses a hoist to eject them with the tray, completing one cycle. |
โป ๋ง๋ก์ ๋ด์ ๋ชจ๋ ์ฝํ ์ธ ๋ฅผ ๋ฌด๋จ์ผ๋ก ๋ณต์ฌ ๋ฐ ์ฌ์ฐฝ์ํ ๊ฒฝ์ฐ ๋ถ์ ๊ฒฝ์๋ฐฉ์ง๋ฒ ๋ฐ ์ ์๊ถ๋ฒ์ ์๋ฐ๋ ์ ์์์ ๋ฐํ๋๋ค.
